Image de Universal Rotating TV Bracket TV Mount for LCD TVs, LED TV 32-55

Universal Rotating TV Bracket TV Mount for LCD TVs, LED TV 32-55

SKU: FS9100275
Fit for 26 "- 55" TV sets rotation adjustment ± 60 °
Reproduction is welcome and allowed for free circulation only.


Universal Rotating TV Bracket TV Mount for LCD TVs, LED TV 32-55

Description
max. lifting capacity 35 kg
for 26 ″ - 55 ″ TVs
right-left rotation adjustment up to ± 60 °
tilt adjustment in the range of + 8 ° / -12 °
screen tilt correction ± 3 °
adjustable distance from the wall in the range of 57 ~ 367mm
available in black

CHARACTERISTIC
designed for LED LCD TVs
high-quality workmanship with attention to detail
unique design
tilt adjustment
swivel arm
small distance from the wall (flat design)
tilt correction (reduction of assembly errors)
compliant with the VESA standard
very solid workmanship
available in black

TECHNICAL PARAMETERS
max. lifting capacity 35 kg
for 26 "- 55" TV sets
rotation adjustment ± 60 °
tilt adjustment in the range of + 8 ° / -12 °
screen tilt correction ± 3 °
adjustable distance from the wall in the range of 57 ~ 367mm
VESA compatible (mounting hole spacing) standard:
VESA 200x100 (200 x 100 mm hole spacing)
VESA 200 (200 x 200 mm hole spacing)
VESA 300x200 (hole spacing 300 x 200 mm)
VESA 300 (hole spacing 300 x 300 mm)
VESA 400x200 (hole spacing 400 x 200 mm)
VESA 400 (hole spacing 400 x 400 mm)
and all the others in the range from 100 × 100 to 400 × 400 mm.
MOUNTING KIT

Screw M5 × 14mm - 4 pcs.
Screw M6 × 14mm - 4 pcs.
Screw M6 × 30mm - 4 pcs.
Screw M8 × 20mm - 4 pcs.
Screw M8 × 45mm - 4 pcs.
Distance 15mm - 4 pcs.
Washer ⌀6 × 16 - 4 pcs.
Washer ⌀6 × 14 - 4 pcs.
Washer ⌀8 × 16 - 4 pcs.
Screw M6x60 - 4 pcs.
Expansion plug 10 × 50 - 4 pcs.

SET COMPOSITION
handle
set of screws *
installation instructions
* standard / universal screws suitable for most televisions are included, if they do not fit, you need to buy the appropriate screws on your own!

How to check if the bracket will fit the TV?
When choosing the right TV mount, you should first of all pay attention to the weight of the TV and the spacing of the VESA mounting holes, the size of the screen itself is indicative. For information on the TV's VESA compliance, see the user manual or the manufacturer's website. You can also check and measure the spacing of the holes yourself.

The VESA standard specifies the locations of the four mounting holes on the back of the TV. The spacing of these holes depends on the make, model and size of the screen. Dimensions are given in millimeters: the first parameter specifies the distance between the holes horizontally (left - right), and the second parameter specifies the distance between the mounting holes vertically (top - bottom).
