Picture of QSFP-DD800 800 Gbps to 2* QSFP112 400 Gbps DAC

QSFP-DD800 800 Gbps to 2* QSFP112 400 Gbps DAC

SKU: FS9103740
QSFP-DD800 800 Gbps to 2* QSFP112 400 Gbps DAC
Reproduction is welcome and allowed for free circulation only.


Product Description: QSFP-DD800 to 2* QSFP112 800 Gbps to 2*400 Gbps Passive Direct Attach Copper Cable
Series: 800-GBPS QSFP-DD800
Data Rate: 800G to 2X 400G Giga Ethernet
Bulk Cable: Zhaolong LONGSPEED® Twin-Ax  HSC Series
Cable Construction: 2x8Pair ,Round Cable
Signal Wire Size: 28-30 AWG
Cable Length : 0.5-2.0 M
LSZH Products Available
Temperature Range: 0-70℃

Features and Benefits
Compliant with QSFP-DD800 MSA Standard
Compliant with IEEE 802.3ck (800GBASE-CR8) Standard
Compliant with IEEE 802.3cd (400GBASE-CR8) Standard
Compliant with IEEE 802.3bj (200GBASE-CR8) Standard
Compliant with IEEE 802.3by (25 Ethernet) Standard
Data Rate: 112G PAM-4 Per Channel Total Bandwidth 800 Gbps (8 Lane 112G PAM-4)
Low Power Consumption
Management Interface follows CMIS Standard and can be customized
Excellent SI Performance
Custom Colors For Pull Tab

Market and Application
High-Performance Computing (HPC)
Network Interface Cards (NIC's)
Data Center and Enterprise Storage Systems
Telecommunication Equipment
800Gbps Ethernet
InfiniBand™  8X NDR/HDR/EDR


Mechanical Performance
QSFP-DD800 Module
Module Insertion:  90N Maximum
Module Extraction : 50N Maximum
Latch Retention: 125N Minimum
Rated Durability Cycles: 50 Cycles Minimum

QSFP112 Module
Module Insertion:  60N Maximum
Module Extraction: 30N Maximum
Latch Retention: 90N Minimum
Rated Durability Cycles: 50 Cycles Minimum


Electrical Performance
QSFP-DD800 Module
Supply Voltage 3.3 VDC +/- 5%
Supply Current :0.03A Max at 3.135V
Power Consumption (DAC) : 0.125 Watt Max
Voltage: 30VAC per contact
Current: 0.5A/Signal Contact

QSFP112 Module
Supply Voltage 3.3 VDC +/- 5%
Supply Current :0.03A Max at 3.135V
Power Consumption (DAC) : 0.125 Watt Max
Voltage: 30VAC per contact
Current: 0.5A/Signal Contact


Signal Integrity
 IEEE 802.3ck (800GBASE-CR8)
 IEEE 802.3cd (400GBASE-CR8)
 IEEE 802.3bj (200GBASE-CR8)
 IEEE 802.3by (25 Ethernet)
 InfiniBand™ 8X NDR (800G) /HDR(400G) / EDR(200G)


Product Environmental Compliance
1. RoHS2.0: Compliant
2. China RoHS: Yes
3. REACH SVHC: Yes
4. Low-Halogen Products: Optional
