Picture of 24.0-inch 1920*1200-resolution 60HZ computer LCD module

24.0-inch 1920*1200-resolution 60HZ computer LCD module

SKU: FS9103745
Diagonal Size 24.0" Panel Type a-Si TFT-LCD, LCM Resolution 1920(RGB)×1200, WUXGA 94PPI Pixel Format RGB Vertical Stripe Active Area 518.4(W)×324(H) mm Bezel Opening 522.6(W)×328.2(H) mm Outline Size 546.4(W)×350(H) ×10.7(D) mm Surface Antiglare (Haze 25%), Hard coating (3H) Brightness 250 cd/m² (Typ.) Contrast Ratio 1000:1 (Typ.) (TM) Viewing Angle
Reproduction is welcome and allowed for free circulation only.


24.0-inch 1920*1200-resolution 60HZ computer LCD module


Diagonal Size
24.0"
Panel Type
a-Si TFT-LCD, LCM
Resolution
1920(RGB)×1200, WUXGA 94PPI
Pixel Format
RGB Vertical Stripe
Active Area
518.4(W)×324(H) mm
Bezel Opening
522.6(W)×328.2(H) mm
Outline Size
546.4(W)×350(H) ×10.7(D) mm
Surface
Antiglare (Haze 25%), Hard coating (3H)
Brightness
250 cd/m² (Typ.)
Contrast Ratio
1000:1 (Typ.) (TM)
Viewing Angle
89/89/89/89 (Typ.)(CR≥10)
Display Mode
ADS, Normally Black, Transmissive
Best View on
Symmetry
Response Time
14 (Typ.)(G to G)
Display Colors
16.7M 72% NTSC
Lamp Type
13S3P WLED , 30K hours , Without Driver
Frequency
60Hz
Touch Screen
Without
Panel Weight
2.58Kgs (Typ.)
Application

Signal Interface
LVDS (2 ch, 8-bit) , 30 pins Connector
Input Voltage
5.0V (Typ.)
Environment
Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C


Key attributes
Other attributes
Place of Origin
China
Brand Name
BOE
Resolution
1920*1200
Interface
LVDS
Product Name
LCD Dispaly Screen
Viewing Angle
89/89/89/89 (Typ.) (CR≥10)
Active Area
518.4(W)*324(H) mm
Frame Rate
60HZ
Contrast Ratio
1000:1 (Typ.) (TM)
WEIGHT
2.58Kgs (Typ.)
Power Supply
5.0V (Typ.)
Environment
Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
Packaging and delivery
Packaging Details
Standard sealed carton packaging with foam protection
attribute-list
Supply Ability
3200 Piece/Pieces per Month
Show more
Lead time
Quantity (pieces) 1 - 10 11 - 50 > 50
Lead time (days) 5 7 To be negotiated
